Top Interturn Impact Withstand Voltage Tester Manufacturers and Suppliers in China

Interturn Impact Withstand Voltage Tester

DEMIKS has specialized Interturn Impact Withstand Voltage Testers which have high accuracy and reliability to meet the industry’s grit standards. Being a known manufacturer in China, DEMIKS serves all Interturn Impact Withstand Voltage Testers needed. Reach out for further information.

DZJ-500S Interturn Impact Withstand Voltage Tester

Gap In Insulation: Identifies faults in inner wire insulation resulting from processes during manufacturing, which helps maintain the reliability of machinery.
Analysis of Pulse Waveform: Conducts quick assessment of interturn insulation breakdown with a comparison of high voltage pulses.
Effective Fault Detection Methods: Identifies shorts of various types - turn-to-turn, corona discharge, partial short, or wiring errors and imbalance of coils.
Advanced Integration Features: Incorporates an oscilloscope for monitoring waveforms in real-time that can be adjusted to the user’s preferences.
Accuracy and Trustworthiness: Achieves precision and a low failure rate which aligns with the best domestic technologies strived for.

DZJ-500S Interturn Impact Withstand Voltage Tester-1

DZJ-500S Interturn Impact Withstand Voltage Tester-2

DZJ-500S Interturn Impact Withstand Voltage Tester-3

DZJ-500S Interturn Impact Withstand Voltage Tester-4

DZJ-500S Interturn Impact Withstand Voltage Tester-5

DZJ-500S Interturn Impact Withstand Voltage Tester-6

Parameter	Specification	Parameter	Specification
Peak Voltage	500～15,000V, continuously adjustable	Peak Voltage Accuracy	≤5% (1kV~15kV)
Waveform Rise Time	0.5μs or 0.2μs	Power Supply	220V±10%, 50Hz
Power Consumption	≤800W (DZJ-112), ≤100W (DZJ-500S)
